ND:YLF Laser Crystal Rod used at 1047nm and 1053nm

Brand Name : Crystro

Model Number : JCR20250208-01

Certification : SGS/ROHS/REACH

Place of Origin : China

MOQ : 1pc

Supply Ability : 500pcs per month

Delivery Time : 4-12 weeks

Packaging Details : membrane elastic box

Material : ND:YLF

Doping concentration : 0.5%-1%

Applied wavelength : 1047nm and 1053nm

Dimension : Customized

Orientation : a cut/c cut

Laser damage threshold of film layer : 10J/CM2

Contact Now

ND:YLF Laser Crystal Rod used at 1047nm and 1053nm

Nd:YLF features an extremely large fluorescence line width, low thermal lensing effect and natural polarization. It is widely used in mode-locked lasers, continuous lasers and material processing fields. As an alternative medium to Nd:YAG, Nd:YLF is used to work in the near-infrared region, generating lasers at wavelengths of 1047nm and 1053nm. It can be applied in linearly polarized resonators, mode-locked lasers, diode-pumped Nd:YLF lasers and Ti:sapphire chirped pulse amplifiers.

Main features:

Natural polarization；
Extra-wide fluorescent line width；
High ultraviolet transparency；
The thermal lensing effect is smaller than that of YAG crystals；
Continuous lasers have a relatively low excitation light threshold；
Suitable for medium repetition frequency, high average power Q-switched mode-locking operation；
Effective single-mode operation, high power output and low beam divergence angle；

Nd:YLF Properties

Crystal Structure Tetragonal
Melting Point 825℃
Moh Hardness 5
Density 3.95g/cm3
Thermal Conductivity 0.06W/cm/K
Thermal Expansion Coefficient [100]方向:13×10-6/K
[001]方向:8×10-6/K
Young's Modulus 7.5×1011dynes cm-2
Tensile Strength 3.3×108dynes cm-2
